Mainboard Asus ROG CROSSHAIR X870E EDITION 20 (AMD X870/ Socket AM5/ E-ATX/ 4 khe ram)

Mã SP: 0 | Bảo hành: 36 Tháng | Tình trạng: Còn hàng

Lượt xem: 1 | (0 đánh giá)

Giá hiện tại : 99.990.000 đ

Mô tả tóm tắt sản phẩm

Chipset: AMD X870
Socket: Socket AM5
Chuẩn kích thước: E-ATX
Số cổng xuất hình: 1 x HDMI, 1 x DisplayPort
Hỗ trợ RAM: 4 khe DDR5, tối đa 256GB
Hỡ trợ CPU: AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors

Xem thêm

Số lượng:

ĐẶT MUA NGAY Giao hàng tận nơi nhanh chóng, thuận tiện THÊM VÀO GIỎ HÀNG Thêm vào giỏ để chọn tiếp TRẢ GÓP CHỈ TỪ 0%

Hotline tư vấn
1800.6321

SẢN PHẨM CÒN HÀNG TẠI

CHÍNH SÁCH MUA HÀNG

Bảo hành chính hãng tới 5 năm Bảo hành tận nơi siêu tốc 3h Đổi mới khi lỗi 30 ngày đầu Trả góp lãi suất 0% Giao hàng toàn quốc

HOTLINE HỖ TRỢ

Tổng đài miễn cước: 1800.6321 Tư Vấn PC: 0964.812.876 Tư Vấn Laptop: 0964.812.876 Kỹ Thuật Hà Nội: 0243.877.7777 - Nhánh 1 Kỹ Thuật TPHCM: 0243.877.7777 - Nhánh 2

Thông số kỹ thuật

Bộ nhớ RAM
Khe cắm RAM	4 khe ram
Loại RAM	DDR5
Bus RAM hỗ trợ	4 x DIMM slots, max. 256GB, DDR5 Supports up to 8600+MT/s(OC)/8200+MT/s(OC) with Ryzen 9000 Series Processors, 9600+MT/s(OC)/9200+MT/s(OC) with Ryzen 8000 Series Processors, 8000+MT/s(OC)/8000+MT/s(OC) with Ryzen 7000 Series Processors, ECC and Non-ECC, Un-buffered DIMM Dual Channel Memory Architecture Supports AMD Extended Profiles for Overclocking (EXPO) Supports DIMM Fit and DIMM Fit Pro ASUS Enhanced Memory Profile (AEMP) NitroPath DRAM Technology
Kết nối
Kết nối mạng	1 x Realtek 10Gb Ethernet 1 x Realtek 5Gb Ethernet
Thông số (Lan/Wireless)	Wi-Fi 7 2x2 Wi-Fi 7 (802.11be) Supports 2.4/5/6GHz frequency band Supports Wi-Fi 7 320MHz bandwidth, up to 6.5Gbps transfer rate. Bluetooth® v5.4
Khe cắm trong	AMD Ryzen™ 9000 & 7000 Series Desktop Processors 2 x PCIe 5.0 x16 slots with PCIe Q-Release Switch (supports x16 or x8/x8 or x8/x4/x4 or x4/x4/x4/x4 modes) AMD Ryzen™ 8700 & 8600 & 8400 Series Desktop Processors 2 x PCIe 4.0 x16 slots with PCIe Q-Release Switch (only supports PCIEx16(G5)_1 & total bandwidth for x8, PCIEx16(G5)_2 will run at PCIe 3.0 x4) AMD Ryzen™ 8500 & 8300 Series Desktop Processors 2 x PCIe 4.0 x16 slots with PCIe Q-Release Switch (only supports PCIEx16(G5)_1 & total bandwidth for x
Khe cắm mở rộng	Supports up to 9 x M.2 slots and 4 x SATA 6Gb/s ports AMD Ryzen™ 9000 & 7000 Series Desktop Processors M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) Hyper M.2_1 slot (Key M) via ROG Hyper M.2 card, type 2230/2242/2260/2280/22110 (suppports PCIe 5.0 x4 mode) Hyper M.2_2 slot (Key M) via ROG Hyper M.2 card, type 2230/2242/2260/2280/22110 (suppports PCIe 5.0 x4 mode) AMD Ryzen™ 8700 & 8600 & 8400 Series Deskto
Cổng giao tiếp ngoài	Ports 2 x USB4® (40Gbps) ports (2 x USB Type-C®) 12 x USB 10Gbps ports (8 x Type-A + 4 x USB Type-C®) 1 x Wi-Fi Module 2 x Realtek 10Gb Ethernet ports 2 x LED-illuminated audio jacks 1 x Optical S/PDIF out port 1 x BIOS FlashBack™ button 1 x Clear CMOS button
Thông tin chung
Chipset	AMD X870
Socket	Socket AM5
Kích thước Main	E-ATX
Hỗ trợ CPU	AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors
Chi tiết Vga	2 x USB4® (40Gbps) ports support USB Type-C® display outputs Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications. Supports max. 4K@60Hz as specified in DisplayPort 1.4a
Âm thanh	ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082
Mô tả khác	Đang cập nhật
Phụ kiện kèm theo	AIO Cooler - ROG RYUJIN 360 EDITION 20 Integrated CPU / VRM copper liquid cold plate and radiator Swivel dual 6.67 AMOLED LCD display 3 x 120mm Pre-connected Edition 20 Fans 1 x ROG RYUJIN 360 EDITION Screw Set Cables 1 x 1-to-4 ARGB splitter cable 1 x 1-to-2 ARGB splitter cable 2 x 1-to-3 fan splitter cable 2 x ROG weave SATA 6G cable packages ROG Hyper M.2 Card with Heatsink 1 x ROG Hyper M.2 with heatsink 1 x M.2 pad package for ROG Q-DIMM.2 2 x Thermal pad for ROG Hyper M.2 Card ROG Q-DIMM

Bộ nhớ RAM
Khe cắm RAM	4 khe ram
Loại RAM	DDR5
Bus RAM hỗ trợ	4 x DIMM slots, max. 256GB, DDR5 Supports up to 8600+MT/s(OC)/8200+MT/s(OC) with Ryzen 9000 Series Processors, 9600+MT/s(OC)/9200+MT/s(OC) with Ryzen 8000 Series Processors, 8000+MT/s(OC)/8000+MT/s(OC) with Ryzen 7000 Series Processors, ECC and Non-ECC, Un-buffered DIMM Dual Channel Memory Architecture Supports AMD Extended Profiles for Overclocking (EXPO) Supports DIMM Fit and DIMM Fit Pro ASUS Enhanced Memory Profile (AEMP) NitroPath DRAM Technology
Kết nối
Kết nối mạng	1 x Realtek 10Gb Ethernet 1 x Realtek 5Gb Ethernet
Thông số (Lan/Wireless)	Wi-Fi 7 2x2 Wi-Fi 7 (802.11be) Supports 2.4/5/6GHz frequency band Supports Wi-Fi 7 320MHz bandwidth, up to 6.5Gbps transfer rate. Bluetooth® v5.4
Khe cắm trong	AMD Ryzen™ 9000 & 7000 Series Desktop Processors 2 x PCIe 5.0 x16 slots with PCIe Q-Release Switch (supports x16 or x8/x8 or x8/x4/x4 or x4/x4/x4/x4 modes) AMD Ryzen™ 8700 & 8600 & 8400 Series Desktop Processors 2 x PCIe 4.0 x16 slots with PCIe Q-Release Switch (only supports PCIEx16(G5)_1 & total bandwidth for x8, PCIEx16(G5)_2 will run at PCIe 3.0 x4) AMD Ryzen™ 8500 & 8300 Series Desktop Processors 2 x PCIe 4.0 x16 slots with PCIe Q-Release Switch (only supports PCIEx16(G5)_1 & total bandwidth for x
Khe cắm mở rộng	Supports up to 9 x M.2 slots and 4 x SATA 6Gb/s ports AMD Ryzen™ 9000 & 7000 Series Desktop Processors M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) Hyper M.2_1 slot (Key M) via ROG Hyper M.2 card, type 2230/2242/2260/2280/22110 (suppports PCIe 5.0 x4 mode) Hyper M.2_2 slot (Key M) via ROG Hyper M.2 card, type 2230/2242/2260/2280/22110 (suppports PCIe 5.0 x4 mode) AMD Ryzen™ 8700 & 8600 & 8400 Series Deskto
Cổng giao tiếp ngoài	Ports 2 x USB4® (40Gbps) ports (2 x USB Type-C®) 12 x USB 10Gbps ports (8 x Type-A + 4 x USB Type-C®) 1 x Wi-Fi Module 2 x Realtek 10Gb Ethernet ports 2 x LED-illuminated audio jacks 1 x Optical S/PDIF out port 1 x BIOS FlashBack™ button 1 x Clear CMOS button
Thông tin chung
Chipset	AMD X870
Socket	Socket AM5
Kích thước Main	E-ATX
Hỗ trợ CPU	AMD Socket AM5 for AMD Ryzen™ 9000 & 8000 & 7000 Series Desktop Processors
Chi tiết Vga	2 x USB4® (40Gbps) ports support USB Type-C® display outputs Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications. Supports max. 4K@60Hz as specified in DisplayPort 1.4a
Âm thanh	ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4082
Mô tả khác	Đang cập nhật
Phụ kiện kèm theo	AIO Cooler - ROG RYUJIN 360 EDITION 20 Integrated CPU / VRM copper liquid cold plate and radiator Swivel dual 6.67 AMOLED LCD display 3 x 120mm Pre-connected Edition 20 Fans 1 x ROG RYUJIN 360 EDITION Screw Set Cables 1 x 1-to-4 ARGB splitter cable 1 x 1-to-2 ARGB splitter cable 2 x 1-to-3 fan splitter cable 2 x ROG weave SATA 6G cable packages ROG Hyper M.2 Card with Heatsink 1 x ROG Hyper M.2 with heatsink 1 x M.2 pad package for ROG Q-DIMM.2 2 x Thermal pad for ROG Hyper M.2 Card ROG Q-DIMM

Xem thêm thông số
